Pulley input type precision reduction gearhead model (Solid Series)
The RD2 series introduces the pulley type as a new input option. The pulley input allows for design flexibility with regard to the motor position. The speed ratio can also be adjusted using the pulley. This product enables flexible designs to be created according to the usage situation of the customer.
Product Features
- Backlash less than 1 arc. min.
- Lost motion less than 1 arc. min.
- Pulley input type
- Internal main bearing
- Major motor coupling Parts included
- Sealed grease
